AR-2A MSRP: $1,678.00 - $2,390.00
LE/Govt.: $1,346.50 - $1,913.50
We will beat ANY advertised price!
Dual Beam Aiming LASER

  The powerful DBAL-A2 is power packed with a focusable IR LASER illuminator, an Infrared Aiming LASER Pointer for use with Night Vision Devices, and your choice of a visible Red Super Power Point or visible Green Ultra Power Point Aiming LASER pointer, which is five times more visible than traditional Red LASERS and the maximum allowed by law for maximum daytime visibility. When every second counts, the versatile DBAL-A2 is the right choice for any mission. Designed for maximum operational versatility while keeping the weight down and size to a minimum, the DBAL-A2 is Combat Ready and considered to be the most innovative and multi-functional LASER system on the market today.









The DBAL-A2 currently in service by Special Operations Forces  worldwide and is also under contract with the US Department of Defense as the AN/PEQ-15A, features the original housing style with dual activation switches and raised Windage and Elevation adjusters. All other DBAL-A2 models feature a new streamlined housing, improved Windage and Elevation adjusters and a single activation switch. Frequently compared to the plastic-molded AN/PEQ-15, the DBAL-A2 delivers superior operational longevity due to its all metal housing and mounting system.

The new DBAL-A2H is the High-Power Model that offers more unbeatable advantages with the addition of a 200mW IR pointer/illuminator.

Manufactured in the USA using the finest quality materials, with a 1 Year Warranty.


Your choice of either a long or short top rail; or DBAL-IR with high power IR Pointer + IR illuminator for the maximum advantage in low-light confrontations.

EXPORT LICENSE REQUIRED.
IR LASER's are restricted to Gov't & Law Enforcement agencies only.
Please be prepared to provide credentials when ordering.

Features

  *  Instantly switch between LASER functions:
  * Visible Pointer only * IR Pointer only * IR Illuminator only
  * Infrared Pointer & Infrared Illuminator combined
  *  Single adjustment mechanism for both IR & Visible LASER's
  *  Hi-Power & Lo-Power (Class I) modes of operation
  *  Fully adjustable for Windage & Elevation for Pin-Point Accuracy
  *  Activation and Low Battery Indicator Light
  *  Meets MIL-STD-810F for adverse environmental conditions
  *  Mounts on all MIL-SPEC-1913 rails
  *  Positive On/Off Kill Switch prevents accidental activation
  *  Precision glass lens produces a virtually round laser point
  *  Waterproof to 20 Meters



Supplied with:
Quick Release Mount, Battery, (1) 3-Volt 123A Lithium Battery (Optional 1.5-Volt AA Battery available on some models), 7" Right Angle Remote Cable Pressure Pad Switch, Optical Pattern Generators, and Nylon Belt Pouch (Specify cable length if different from standard)
  *  Integrated Momentary Remote Pressure Pad Switch & Activation Switch
      *  Single-Tap - Enables momentary activation
      *  Double-Tap - Instantly activates the LASER in a continuous "ON Mode".
      *  Built-in safety returns the unit to momentary activation after 5 minutes.
  *  The Pressure Pad provides a tactile (silent) click that indicates when the switch has been activated

DBAL-A2 Dual Beam Aiming Laser
Laser Specifications
Visible/IR Pointer IR Illuminator
Type: Laser Class IIIa/Class IIIb

Laser Class IIIb
Hi-Power Output: <5 mW/<35mW/<50mW

<50 mW
Lo-Power Output: <1 mW/<1mW

<1 mW
Wavelength: ± 30nm Green = 532nm/Red = 635nm

840nm
Beam Diameter: 8 mm at 25 m

8 mm at 25 m
Beam Divergence: ± 3mrad 0.5 x 1.5/0.5 x 1mrad

1 -105 mrads
Range/Visibility: Night Day
Visible Pointer: 500m

30m
IR Pointer: 600m
IR Illuminator: 2000m
Hi-PWR IR illuminator 5000m
Battery Type / Life: (1) 123A 3-Volt Lithium Battery / 5 hours
Mechanical Specifications
Material: Anodized Aircraft Aluminum 6061T-6
Dimension: in L: 3.45 " W: 2.91" H: 1.9"
Dimension: cm L: 8.76cm W:7.4cm H: 4.8cm
Total Weight (oz./g) 8.2 ounces

232 grams
Environment: Waterproof to 3 Meters
Typical Weapon Types:

AK-47, AK-74, Armalite, Barrett Rifle, Bushmaster, DPMS Panther Arms, FAMAS, FN Herstal, Heckler & Koch, IMI, M240/M249, M-16/AR-15/M-4, MP5 Submachine Gun, SIG Arms, Styler
LDI Patent No.: 5,581,898
Warranty: 1 Year
NSN: 5855-01-535-6166 & 5855-01-579-0062
Choose your product and Color

MODELS Available in Foliage Green, Desert Sand or Black, AA Battery Option available on some models

DBAL-A2

 * IR Pointer (<50mW)

 * IR Pointer/Illuminator (<50mW)

 * Choice of

     * Red Visible Pointer (<5mW) or

     * Green Visible Pointer (<5mW, <30mW or <50mW)


Part# Description  MSRP

 Gov't Price
40090
Black
123A  Battery		 DBAL-A2 AN/PEQ-15A U.S. DoD Model - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, 3-Volt 123A Lithium Battery, Quick Release Mount, Dual Activation Switches, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Belt Pouch NSN: 5855-01-535-6166   $1,678.00   $1,245.00
40090A
Black
AA Battery		 DBAL-A2 AN/PEQ-15A U.S. DoD Model - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, AA Battery, Quick Release Mount, Dual Activation Switches, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Belt Pouch NSN: 5855-01-535-6166   $1,678.00   $1,245.00
40090F
Foliage Green
123A  Battery		 DBAL-A2 AN/PEQ-15A U.S. DoD Model - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, 3-Volt 123A Lithium Battery, Quick Release Mount, Dual Activation Switches, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Belt Pouch NSN: 5855-01-579-0062   $1,678.00   $1,245.00
40090FA
Foliage Green
AA Battery		 DBAL-A2 AN/PEQ-15A U.S. DoD Model - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, AA Battery, Quick Release Mount, Dual Activation Switches, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Belt Pouch NSN: 5855-01-579-0062   $1,678.00   $1,245.00
40090D
Desert Sand
123A  Battery		 DBAL-A2 AN/PEQ-15A U.S. DoD Model - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert Sand, 3-Volt 123A Lithium Battery, Quick Release Mount, Dual Activation Switches, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Belt Pouch  $1,678.00   $1,245.00
40090DA
Desert Sand
AA Battery		 DBAL-A2 AN/PEQ-15A U.S. DoD Model - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert Sand, AA Battery, Quick Release Mount, Dual Activation Switches, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Belt Pouch  $1,678.00   $1,245.00

40200
Black
123A  Battery		 DBAL-A2 - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,678.00   $1,245.00
40200A
Black
AA  Battery		 DBAL-A2 - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,678.00   $1,245.00
40200F
Foliage Green
123A  Battery		 DBAL-A2 - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,678.00   $1,245.00
40200FA
Foliage Green
AA  Battery		 DBAL-A2 - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,678.00   $1,245.00
40200D
Desert Sand
123A  Battery		 DBAL-A2 - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert sand, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,678.00   $1,245.00
40200DA
Desert Sand
AA  Battery		 DBAL-A2 - w/Visible Red Pointer (635nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert Sand, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,678.00   $1,245.00

40171
Black
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,958.00   $1,452.00
40171A
Black
AA  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,958.00   $1,452.00
40171F
Foliage Green
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from std), Optical Pattern Generators, Nylon Pouch  $1,958.00   $1,452.00
40171FA
Foliage Green
AA  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,958.00   $1,452.00
40171D
Desert Sand
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert sand, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,958.00   $1,452.00
40171DA
Desert Sand
AA  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<5mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert Sand, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $1,958.00   $1,452.00

40172
Black
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<30mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $2,119.00   $1,571.00
40172A
Black
AA  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<30mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $2,119.00   $1,571.00
40172F
Foliage Green
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<30mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from std), Optical Pattern Generators, Nylon Pouch  $2,119.00   $1,571.00
40172FA
Foliage Green
AA  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<30mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $2,119.00   $1,571.00
40172D
Desert Sand
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<30mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert sand, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $2,119.00   $1,571.00
40172DA
Desert Sand
AA  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<30mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert Sand, 1.5-Volt AA Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $2,119.00   $1,571.00

40173
Black
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<50mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Black, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $2,390.00   $1,773.00
40173F
Foliage Green
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<50mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Foliage Green, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from std), Optical Pattern Generators, Nylon Pouch  $2,390.00   $1,773.00
40173D
Desert Sand
123A  Battery		 DBAL-A2 - w/Visible Green Pointer (532nm)(<50mW) Infrared Pointer (835nm)(<50mW) & Infrared Pointer/Illuminator (835nm)(<50mW), Desert sand, 3-Volt 123A Lithium Battery, Quick Release Mount, Single Activation Switch, 7" Remote Cable Pressure Pad Switch (Specify cable length if different from standard), Optical Pattern Generators, and Nylon Pouch  $2,390.00   $1,773.00

Gov't Only Green = (532nm)  Red = (635nm) IR = (835nm) unless otherwise specified



Accessories

Part#

Description

 MSRP

Gov't Price
FA05219-7 Remote Cable Switch - 7" Black  $ 68.00 $50.00
FA05805-01 Battery Cap, Black  $ 31.00 $23.00
FA05805-02 Battery Cap, Foliage Green  $  31.00 $23.00
FA05805-03 Battery Cap, Desert Sand  $ 31.00 $23.00
F3693-01 Battery Cap Strap, Black  $ 5.00 $4.00
F3693-02 Battery Cap Strap, Foliage Green  $ 5.00 $4.00
F3693-03 Battery Cap Strap, Desert Sand  $ 5.00 $4.00
FC01223 Safety Screw - Hexagon Head, Blue  $ 5.00 $4.00
C00098 O-Ring, Black  $ 3.00 $3.00
FA05779-01 Exit Port Cover Single Beam, Black  $ 7.00 $5.00
FA05779-02 Exit Port Cover Single Beam, Foliage Green  $ 7.00 $5.00
FA05779-03 Exit Port Cover Single Beam, Desert Sand  $ 7.00 $5.00
FA06883-01 Exit Port Cover Dual Beam, Black  $ 7.00 $5.00
FA06883-02 Exit Port Cover Dual Beam, Foliage Green  $ 7.00 $5.00
FA06883-03 Exit Port Cover Dual Beam, Desert Sand  $ 7.00 $5.00
FA05233-01 Pattern Generators (Set of 5), Black  $34.00 $25.00
FA05233-02 Pattern Generators (Set of 5), Foliage Green  $34.00 $25.00
FA05233-03 Pattern Generators (Set of 5), Desert Green  $34.00 $25.00
FA06111-01 DBAL-A2 AN/PEQ-15 US DoD Repair Parts Complete Kit, Black  $181.00 $135.00
FA06111-02 DBAL-A2 AN/PEQ-15 US DoD Repair Parts Complete Kit, Foliage Green  $181.00 $135.00
FA06111-03 DBAL-A2 AN/PEQ-15 US DoD Repair Parts Complete Kit, Desert Sand  $181.00 $135.00
33053-01 DBAL-A2 Repair Parts Complete Kit, Black  $181.00 $135.00
33053-02 DBAL-A2 Repair Parts Complete Kit, Foliage Green  $181.00 $135.00
33053-03 DBAL-A2 Repair Parts Complete Kit, Desert Sand  $181.00 $135.00


Part#

Description

 MSRP

Gov't Price
FA05349-01 Neutral Density Filter, Black , for IR Pointer  $10.00 $8.00
FA05349-02 Neutral Density Filter, Foliage Green  for IR Pointer  $ 10.00 $8.00
FA05349-03 Neutral Density Filter, Desert Sand for IR Pointer  $ 10.00 $8.00


Part#

Description

 MSRP

Gov't Price
FA06883-01 Exit Port Cover Black for VIS/IR Pointer  (Old PN: F4762-01)  $7.00 $5.00
FA06883-02 Exit Port Cover Foliage Green for VIS/IR Pointer  (Old PN: F4762-02)  $7.00 $5.00
FA06883-03 Exit Port Cover Desert Sand for VIS/IR Pointer (Old PN: F4762-03)  $7.00 $5.00


Part#

Description

 MSRP

Gov't Price
FA05779-01 Exit Port Cover Black for IR Illuminator  $7.00 $5.00
FA05779-02 Exit Port Cover Foliage Green for IR Illuminator  $7.00 $5.00
FA05779-03 Exit Port Cover Desert Sand for IR Illuminator  $7.00 $5.00


Part#

Description

 MSRP

Gov't Price
FA05238-01 80˚ Optical Diffuser, Black for IR Illuminator $14.00 $10.00
FA05238-02 80˚ Optical Diffuser, Foliage Green for IR Illuminator $14.00 $10.00
FA05238-03 80˚ Optical Diffuser, Desert Sand for IR Illuminator $14.00 $10.00


Part#

Description

 MSRP

Gov't Price
FA05233-01 Optical Pattern Generators, Black (Set of 5) for IR Pointer  $ 34.00 $25.00
FA05233-02 Optical Pattern Generators, Foliage Green (Set of 5) for IR Pointer  $ 34.00 $25.00
FA05233-03 Optical Pattern Generators, Desert Sand (Set of 5) for IR Pointer  $ 34.00 $25.00


Part#

Description

 MSRP

Gov't Price
C00098 O-Ring, Black  $3.00 $3.00


Part#

Description

 MSRP

Gov't Price
FC01223 Safety Screw - Hexagon Head, Blue  $5.00 $4.00


Part#

Description

 MSRP

Gov't Price
85023 AA Battery Cap, Black  $53.00 $39.00
85023F AA Battery Cap, Foliage Green  $53.00 $39.00
85023D AA Battery Cap, Desert Sand  $53.00 $39.00


Part#

Description

 MSRP

Gov't Price
FA05805-01 Battery Cap, Black  (Old PN: FA04533-01)  $ 31.00 $23.00
FA05805-02 Battery Cap, Foliage Green  (Old PN: FA04533-02)  $  31.00 $23.00
FA05805-03 Battery Cap, Desert Sand  (Old PN: FA04533-03)  $ 31.00 $23.00


Part#

Description

MSRP

Gov't Price
F3693-01 Battery Cap Strap, Black  $ 5.00 $4.00
F3693-02 Battery Cap Strap, Foliage Green  $ 5.00 $4.00
F3693-03 Battery Cap Strap, Desert Sand  $ 5.00 $4.00

Part#

Description

 MSRP

Gov't Price
FA05063-7 7" Right Angle Remote Cable Pressure Pad Switch (Specify length if
different from standard) without threaded receptacle port		  $68.00 $50.00


Part#

Description

 MSRP

Gov't Price
FA05219-7 7" Straight Remote Cable Pressure Pad Switch (Specify length if
different from standard)  without threaded receptacle port		  $68.00 $50.00


Part#

Description

 MSRP

Gov't Price
30102 Accur-Aim Laser Target $36.00 $26.00

Part#

Description

 MSRP

Gov't Price
30102 Accur-Aim Target Strips (35 Pieces) $8.00 $6.00

Part#

Description

 MSRP

Gov't Price
30114-4 3-Volt CR123A Lithium Batteries (4 Pack) $15.00 $11.00

Part#

Description

 MSRP

Gov't Price
30115 1.5-Volt AA Battery, (4 Pack) $7.00 $5.00

Part#

Description

 MSRP

Gov't Price
30204 Daytime Glasses - High Efficiency $107.00 $79.00

Part#

Description

MSRP

Gov't Price
L09151 Nylon Pouch with pocket for spare battery and remote cable
pressure pad switch.
Fits all LASER products and the LAS/TAC 2 Tactical Lights		  $34.00 $25.00

SYSTEM DESCRIPTION

     The DBAL-A2 is a Class IIIb laser device that features a Visible Pointer for daylight and low light operations, as well as an Infrared Pointer and Infrared Illuminator for use with Night Vision Devices. The IR beams can be operated individually or in combination, in both low power (LO PWR) and high power (HI PWR) settings.
     The DBAL-A2 emits a highly collimated beam of IR light for precise aiming of the weapon and a separate IR Illuminator for the target or target area. The IR Illuminator is equipped with an adjustable bezel to vary the size of the illumination beam based on the size and distance to the target. The Visible Pointer and the IR Pointer are co-aligned. The Visible Pointer can be used to boresight the device without the requirement of a Night Vision Device and will simultaneously boresight the IR Pointer.
     The DBAL-A2 can be used as either a handheld illuminator/pointer or it can be weapon mounted using the Throw Lever Mount. In the weapon mounted mode, it can be used to accurately direct fire as well as illuminate and identify targets.
     When the Safety Screw is installed in the rear of the DBAL-A2 housing, it prevents the operator from accessing the non-eye safe, HI PWR modes of operation.



    DBAL-A2 Item Description

1) Battery Cap and Compartment

2) Infrared Illuminator

3) Throw Lever Mount

4) Visible Pointer

5) Boresight Adjusters

6) Infrared Pointer





    DBAL-A2 Major Components

1) Tape Fastener Loop 5/8” (Black) provided to secure the Remote Cable Switch to the weapon in a position convenient to the soldier

2) Tape Fastener Hook ˝" , Black, Remote Cable Switch Pre-attached by the manufacturer to the pressure pad switch.

3) 7" Remote Cable Switch, HI Pressure MOM Remote

4) Optical Instrument Reticle (OIR) (set of 5) used for command and control. When placed in front of the IR Pointer or IR Illuminator that has been focused to a point, they project the shape of a circle ○, square 􀆑, triangle ∆, plus sign +, or T-shape.
The OIR is inserted into the IR Pointer or IR Illuminator aperture of the front cap assembly.
NOTE: Pattern Generators are not designed for accurate aiming of the weapon.

5) Battery, DL 123A 3 Volt Lithium

6) DBAL-A2 Assembly

7) Shipping Case

8 Operator and Field Maintenance Manual provides safety information, equipment information, operating instructions, mounting , zeroing, and operator & unit maintenance procedures











SW POS Marking Use Remarks
1 ON LO PWR On Continuous in Low Power. Activates the selected laser function in LO PWR continuously. DO NOT use in areas where the laser light may be viewed by enemy forces. Primarily used for bore sighting the laser to the weapon in low light conditions.
2 MOM LO PWR Momentary Low-Power. Activates the selected laser function in LO PWR when the Remote Cable Switch or Integrated Momentary Switch is depressed Pressing the pressure pad twice in rapid succession will activate the DBAL-A2 continuously. Pressing the pressure pad again will return the unit to momentary activation
3 OFF OFF The DBAL-A2 will not operate
4 MOM HI PWR Momentary Hi-Power. Activates the selected laser function in HI PWR when the Remote Cable Switch or Integrated Momentary Switch is depressed Pressing the pressure pad twice in rapid succession will activate the DBAL-A2 continuously. Pressing the pressure pad again will return the unit to momentary activation
5 ON HI PWR On Continuous in High Power. Activates the selected laser function in HI PWR continuously. DO NOT use in areas where the laser light may be viewed by enemy forces. Used for higher light levels or for long distance pointing or aiming

W POS Marking Use Remarks
1 VIS POINT Visible LASER Pointer. Selects only the VIS POINT for activation. Used for pointing or aiming at close range in daylight or at longer range in low light conditions
2 IR ILLUM Infrared Illuminator. Selects only the IR ILLUM for activation. Used to provide IR illumination of a target or area that is shadowed.
3 IR POINT & ILLUM IR Pointer&Illuminator
Selects both the IR POINT and ILLUM for activation.		 Illuminates the target area and provides an aiming point for purposes of accurately engaging the target with small arms fire.
4 IR POINT IR Pointer
Selects only the VIS POINT for activation.		 Used for pointing and aiming



Home | Contact Us | About KERIF |  Export Regulations | How to Order

KERIF Night Vision
(702) 324-6463  /  (702) 869-8451 FAX

sales@nitevis.com or kerifnightvision@earthlink.net
