DISCONTINUED
The
new 557.AR223 has been developed to optimize the
functionality of the HWS (HOLOgraphic Weapon Sight). The buttons
have been
moved from the back to the left side for instant
access, allowing a magnifier, Night Vision, or a
BUIS (Back-Up Iron Sight) to fit closely to the HWS body.
This new button position allows the user to operate
the HWS function switches easier than
ever before.
Additionally, a portion of the front base has been
raised to allow the sight to fit over standard hand
guards found on many M-4 or M-16 style weapons.
The 557.AR223 is
configured with a new ballistic matching reticle
image for the M4 carbine. The battle tested
circle/dot reticle will be offered along with a
series of 1 MOA aiming dots that are vertically
aligned and calibrated specifically for the
ballistic drop of
.223 caliber ammunition.
The reticle
provides 4 aiming dots for target distances:
0-300m, 400m, 500m, and 600m.
| Operation | |
| Optics | Transmission Holography - 100% Parallax Free |
| Magnification | 1X |
| Eye Relief | Unlimited |
| Sealing | Fog proof Internal Optics |
| Waterproof | Submersible to 33' |
| Adjustment (per click) | 0.5 MOA (1/2" at 100 yards) |
| Adjustment Range | +/- 40 MOA Travel |
| Mount | 1" MIL-STD-1913 "Picatinny" Rail |
| Return to Zero | Repeatable to 1 MOA after Re-Mounting |
| Heads-Up Display Window | |
| Optical Surfaces | Anti-Glare Coating |
| Window Dimensions | 1.2" x 0.85" (30mm x 23mm) |
| Front Window Material | 1/8" Solid Glass |
| Rear Window Material | Shatter Resistant Laminate 3/16" Thick |
| Field-of-View | 30yds (28m) at a 4" Eye Relief |
| Standard Reticle | AR223 BDC Reticle w/drop point dots for 400, 500, and 600 meters |
| Electrical | |
| Brightness Adj. Range | 110,000:1 brightest to lowest |
| NV Brightness Range: | 1000:1 with NV switch engaged |
| Function Button Location | Left side near the rear of sight |
| Power Source | (2) N Type 1.5V alkaline 3V |
| Battery Life | 1,000 continuous hours (lithium) at nominal setting 12; 600 continuous with AA alkaline |
| Brightness Settings | 30 with scrolling feature (10 settings for NV use) |
| Auto Battery Check Indicator | Flashing reticle upon start-up |
| Auto Shut-down | At 8 hrs- programmable to 4 hrs |
| DIMENSIONS | |
|
Length Width Height |
5.7" (133mm) 2.1" (49mm) 2.8" (71mm) |
| ENVIRONMENTAL DATA | |
| Temperature Range |
-40ºF to 150ºF (AA Lithium) -20ºF to +140 (AA Alkaline) |
| Max Storage Temp. | -80ºC (176ºF) |
